Dianne | 3 Beds · 2 Baths · 1493 SqFt
The mobile home model Dianne has 3 Beds and 2 Baths. This 1493 square foot Double Wide HUD Manufactured Homes is available for delivery in Florida, Georgia, and Alabama.
Ask your housing consultant about the other great features that come standard on the Dianne HUD Manufactured Homes or click the links below to view Skyline Color Selections, Upgrades & Options, and Other Floor Plans!
advertisement
Dianne Price Request
Factory Select Homes
1-800-965-8403
Standard Features
The Dianne is part of the Key Largo Series
CONSTRUCTION FEATURES:
- 2” x 4” Exterior Walls – 16” O. C.
- 1 1⁄2” Plywood Ridge Beam each side – Per Plan
- 8’ Sidewall Height with Flat Ceiling Throughout
- OSB Exterior End Wall Sheathing & Ox Board Sidewall w/House Wrap
- R-33 Ceiling Insulation with Baffle System
- R-11 Sidewall Insulation with Vapor Barrier
- R-22 Floor Insulation
- 7/16” OSB Roof Decking with 3-Tab A/R Shingles with Full
- Underlayment & Painted Drip Edge
- Integrated Covered Porch with PT Decking & Vinyl
- Railings/Pickets – Per Plan
- 12” Gable Overhang with Vented Soffit & Roof Ridge Vent
- Vinyl Lap Siding & Vinyl Window Lineals Front End Wall
- Vinyl Board and Batten Accents – Per Plan
- 61’ & 40” Tall Vinyl Framed Insulated Low-E Windows
- Transom Accent windows at Baths – Per Plan
- 36” 6-Panel Front Door with Deadbolt
- 36” 6-Panel In-Swing Rear Door with Deadbolt
- 19/32” OSB Tongue and Groove Floor Decking
- 2”x6”FloorJoist-16”O.C.
PLUMBING/HVAC:
- PEX Fresh Water Lines
- 30 Gallon Electric Water Heater w/ Pan
- Plumb for Washer
- Interior Main Whole House Water Shut-Off Valve
- Water Shut-Off Valves Throughout
- Engineered Overhead Duct System & Programable Thermostat
- Whole House Ventilation System Multi- Direction Ceiling Vents
- Filter Grill with Filter Installed
- Exterior Faucet
LIVING AREAS:
- 8’ Flat Textured Ceilings Throughout
- 1/2” Finished Drywall Main Living Area
- 31⁄4” Craftsman Trim: Ceiling Trim, Baseboard, Door Casing and Window Trim
- 2” Vinyl Mini- Blinds at Windows
- Vinyl Flooring – w/Transition Bar Throughout
- Raised-Panel Interior Doors w/3-Mortised Hinges
- Ventilated Wire Shelving in Closets
ELECTRICAL:
- 200 Amp Main Panel Box
- Energy Efficient Recessed LED Lighting – throughout
- Led Lights in Living Room
- LED Lights in Bedrooms
- Smoke Detectors with Battery Backup
- Light at All Exterior Doors
- Exterior GFI Receptacle – Per Plan
- Wire and Brace for Ceiling Fan at Living Room; Primary Bedroom; all Secondary Bedrooms
- Vent Fan – Both Baths
- 220V Wire for Dryer
KITCHEN:
- Full Overlay Style Cabinet Construction
- Shaker Style Cabinet Doors w/Black Knobs
- 40” Lined Overhead Cabinets with Adjustable Shelves
- Drawer over Door Base Cabinet Construction
- Counter Depth Refrigerator Cabinet Conceal
- Laminate Countertops w/Crescent Edge per Cabinet
- Whirlpool Appliances:
- European Style SS Stonecrest Rangehood
- 8” Deep Stainless-Steel Double Bowl Kitchen Sink
- 1 Row Ceramic Tile Backsplash at Counter Tops
- 18 Cu. Ft. SS Top Freezer Refrigerator
- 30” SS Smooth Top Electric Range
- Built-In Microwave w/ Trim Ring
BATHROOM:
- 1-Piece Fiberglass Shower w/ Tempered Glass Enclosure – Primary Bath
- 1-Piece Fiberglass Tub at Hall Bath
- Laminate Countertops w/Crescent Edge per Cabinet
- Oval China Sinks with Overflow Drain
- Elongated Commodes
- 1 Row Ceramic Tile Backsplash at Countertops
- 36” High Raised Lav Cabinets
- Light Over Shower/Tub
- 18” x 30” Mirror w/Trim
MIDNIGHT DÉCOR PACKAGE:
- Black Cabinet Door & Drawer Knobs
- Black Passage Door Knobs
- Black Mortised Passage Door Hinges
- Black Pull-Down Kitchen Faucet w/Spray
- Black Metal Lav Faucets
- Black Single Lever Temp-Stop Faucets at Shower and Tub
- Black Pendant Lights at Islands
- Black Coach Light at Exterior Doors
SPECIAL SERIES FEATURES:
- ENERGY STAR CERTIFIED
WARRANTY:
- One Year Limited Warranty
